This is the prototype for the new hayabusa smart car conversion kits being built, although after completed, customers could retrofit the kit into a number of applications from mini coopers or other smaller cars, to reverse trikes, to race cars, to custom built chassis.
The build below will have a custom tube subframe built to hold a built 1300 hayabusa powerplant putting out over 240hp, as well as a custom high amp alternator package. Suspension will consist of 6061 Billet aluminum A-arms with outboard disk brakes, limited slip diff, and engine driven reverse. The front will also be getting a custom tube subframe with custom A-arms. Custom wide body flares and side skirts will be custom built to handle the 9" wider track width (69" overall width), and 3" longer wheelbase, as well as custom fiberglass work for the interior to hold the gauges and switches, then the entire vehicle will be custom painted. The car will have 17x7 rims in the front, 17x9 rims in the rear.
We are currently only offering busa smart kits for the 450 model which is 07 and older. We will be offering a 451 kit for the 08 and newer model in the future. We are willing to waive all prototype fees to the first customer that sends in a 451 car to build the first kit, which will vary slightly from the current kit, just different mounts in the car and a flare kit matched to the newer body. The suspension and subframe will be the same kit offered for the 450.
This is the prototype, so pricing may increase after completion.
|
This is the prototype, so pricing may increase after completion.
Kit A: $5,499
Consist of: 6061 Billet aluminum A-arms, hubs, heims, motor mount plates, subframe (tabbed for hayabusa motor, limited slip diff)
Kit B: $11,499
Consist of everything in kit A plus: Bearing carriers, bearings, seals, stubs, disc brakes, calipers, limited slip diff, diff mount plates and bearings, shocks, as well as the CV/axle kit including: 930 porsche cv's with chromo cages, axles, clips, boots, flanges, bolts.
Kit C: $999
Motor driven reverse.
Kit D: Pricing Not Available at this time
Wide body rear kit and side skirts.
Kit E: Pricing Not Available at this time
Front a-arm conversion kit
Kit F: Pricing Not Available at this time
Front wide body flare kit.
Kit G: $3500
Turnkey hayabusa motor kit, includes wiring, headers, and all sensors.
Kit H: $1800
17" rims/tires, mounted and balanced.
Kit I: $3499
Installation of purchased kits B, D, G and H, as well as powdercoating subframe of customers choice (customers are welcome to send their own busa motor). Includes custom built wire harness, smart body modification for installation of kit.
Built motor package 1: (240 hp crank) ($3599.00)
Includes the following with installation:
Wisco pistons 12:1
intake cam-420 lift
cam sprocket
billet chain tensioner
exhaust cam
springs
bore to 1397
Dyno Jet power commander PCIII USB
Wide body rear kit and side skirts
Feel free to call with any questions, 918-521-3736.
Thanks for looking, Yoshi
|
